Overview
●This product is made of calcium sulfonate thickened and refined high-viscosity mineral oil, and added antioxidant, anti-rust and other additives.
Performance
●It has excellent high temperature resistance, water resistance, mechanical stability, anti-corrosion and oxidation stability.
●Composite calcium sulfonate grease, which can replace composite lithium-based grease and lithium-based grease.
●It is suitable for a wide range of temperatures, especially suitable for lubrication at various high temperatures and high speeds.
Classic data
Performance classification | project | 2 # |
Cone entry | Working cone entry, 25°C, 0.1mm | 283 |
1/4 cone entry, 0.1mm | 72 | 73 |
High temperature performance | Drip point, °C | 300+ |
Reversibility (200°C, 2h) Does not work 1/4 cone entry difference, 0.1mm | -2 | -5 |
Stencil oil separation (100×24h), % | 2.1 | 2 |
Protective properties | Corrosion of copper sheets (T2, 100°C×24h) | qualified |
Anti-corrosion (52°C×48h), grade | 1 | 1 |
Pumping performance | Similar viscosity (-10°C×10S), Pa.S | 606 |
Shear resistance | 1/4 cone entry difference of the drum (2h×60°C), 0.1mm | -1 |
Extreme pressure abrasion resistance | PB value, Kg | 90 |
PD value, Kg | 800 | 800 |
D(40Kg，60min)，mm | 0.41 | 0.39 |
Comprehensive water resistance | Add water 20% anti-rust (52°C×48h), grade | 1 |
Add 20% water to the drum and 1/4 cone entry difference (2h×60°C), 0.1mm | -5 | -3 |
Add 50% water to the drum 1/4 cone entry difference (2h×60°C), 0.1mm | -12 | -6 |
Add 20% water to the PB value of the four-ball machine, Kg | 95 | 95 |
Add 20% water to the PD value of the four-ball machine, Kg | 500 | 500 |
Use
●The specific applicable parts are: mining automobile bearings; The main drive bearing of the ball mill in the concentrator; sintering plant vibrating screen bearings; coke wheel bearings in ironworks; Various continuous casting machine large bag rotary table gear rings; the second cooling zone of the continuous casting machine, the fan section, the tensioning and straightening machine, and the conveyor roller bearing; All kinds of strip mill billet rollers, roughing mill working rolls, finishing mill working rolls, winder bearings, toothed handovers, water pump bearings; seamless steel pipe mill rolling mill shaping roller; the roller bearing of the bottom of the rolling mill and heat treatment furnace of the rolling mill of the medium and heavy plate mill; profiles, wire mill rolling mill work rolls, cold bed bearings, etc. It is also suitable for the lubrication of equipment in other high-temperature, heavy-load, and multi-water situations, such as ships, refractories, chemicals, automobiles, and other industries.
● Applicable operating temperature range; -20℃-220℃。
● Packing: 15kg plastic drum, 180kg iron drum or customized according to customers.
Notes
● Scrub and clean the lubricating surface when using.
● Grease should be placed in a well-ventilated room with a suitable temperature.
● After the bucket lid is used, it should be strictly prevented from sand and dust from being mixed, and the bucket lid should be covered in time after use.
Wrap
15 kg plastic drum, 180 kg iron drum or customized according to customer requirements.
